Lession 2: CREATIONAL PATTERNS – CRAFTING OBJECTS WITH FLEXIBILITY [Detailed Example]

1 Overview

In object-oriented programming (OOP), instantiation is rarely just a call to new. As a code-base grows, dependencies become tangled and requirements shift. Creational Patterns hide construction details, provide controlled extension points, and reduce coupling between client code and concrete classes.

2 Pattern Deep-Dive

2.1 Singleton

1. Definition

Ensure a single object of a class exists and provide a global access point to it.

2. Problem Solved

• Resources that must remain unique: config, loggers, caches.
• Prevent wasted memory or inconsistent state from multiple instances.

3. How It Works

• Private constructor (or guarded __new__).
• Store the unique instance in a static field.
• Expose a public accessor such as getInstance().

4. Pros / Cons

5. Example (Python)

from threading import Lock

class Logger:
    _instance = None
    _lock = Lock()

    def __new__(cls, *args, **kwargs):
        if cls._instance is None:
            with cls._lock:
                if cls._instance is None:          # double-checked
                    cls._instance = super().__new__(cls)
                    cls._instance._setup()
        return cls._instance

    def _setup(self):
        self._file = open("app.log", "a")

    def log(self, msg: str):
        self._file.write(msg + "\n")

2.2 Factory Method

1. Definition

Define an interface for creating an object, but let sub-classes decide which concrete class to instantiate.

2. Problem Solved

A framework cannot foresee every concrete class a plug-in might need, yet wants a standard way to obtain objects.

3. How It Works

• A Creator declares factory_method() → Product.
• Each ConcreteCreator overrides it to return its own ConcreteProduct.

4. Pros / Cons

5. Example (Python)

class Document: ...

class PdfDocument(Document): ...
class WordDocument(Document): ...

class Application:
    def create_document(self) -> Document:      # Factory Method
        raise NotImplementedError

    def open(self):
        doc = self.create_document()
        print(f"Opened {doc.__class__.__name__}")

class PdfApp(Application):
    def create_document(self):
        return PdfDocument()

class WordApp(Application):
    def create_document(self):
        return WordDocument()

app = PdfApp()
app.open()   # → Opened PdfDocument

2.3 Abstract Factory

1. Definition

Provide an interface for creating entire families of related objects without specifying their concrete classes.

2. Problem Solved

• Cross-platform GUI: WindowsButton vs. MacButton, yet client code should stay platform-agnostic.
• Keep products within the same family compatible.

3. How It Works

• AbstractFactory declares methods like create_button() and create_scrollbar().
• ConcreteFactoryWindows / ConcreteFactoryMac implement them, returning platform-specific widgets.

4. Pros / Cons

5. Example (Python)

class Button: ...
class ScrollBar: ...

class WindowsButton(Button): ...
class MacButton(Button): ...

class AbstractFactory:
    def create_button(self) -> Button: ...
    def create_scrollbar(self) -> ScrollBar: ...

class WindowsFactory(AbstractFactory):
    def create_button(self):   return WindowsButton()
    def create_scrollbar(self): ...

class MacFactory(AbstractFactory):
    def create_button(self):   return MacButton()
    # ...

def render_ui(factory: AbstractFactory):
    btn = factory.create_button()
    sb  = factory.create_scrollbar()
    # use btn and sb

factory = WindowsFactory() if platform == "win32" else MacFactory()
render_ui(factory)

2.4 Builder

1. Definition

Separate the construction process of a complex object from its final representation so the same steps can yield different results.

2. Problem Solved

• Objects with many optional parameters lead to telescoping constructors.
• Need to reuse an assembly sequence across varied configurations.

3. How It Works

• Director orchestrates build steps.
• Builder defines steps (add_cheese, add_sauce, …).
• ConcreteBuilder stores interim state and emits the product via build().

4. Pros / Cons

5. Example (Python, fluent style)

class Burger:
    def __init__(self, size, cheese=False, bacon=False):
        self.size, self.cheese, self.bacon = size, cheese, bacon
    def __repr__(self):
        return f"Burger(size={self.size}, cheese={self.cheese}, bacon={self.bacon})"

class BurgerBuilder:
    def __init__(self): self.reset()
    def reset(self):     self._size = 1; self._cheese = False; self._bacon = False; return self
    def size(self, s):   self._size = s; return self
    def cheese(self):    self._cheese = True; return self
    def bacon(self):     self._bacon  = True; return self
    def build(self):     return Burger(self._size, self._cheese, self._bacon)

burger = BurgerBuilder().size(2).cheese().bacon().build()
# → Burger(size=2, cheese=True, bacon=True)

2.5 Prototype

1. Definition

Create new objects by cloning an existing prototype, rather than instantiating from scratch.

2. Problem Solved

• Initialization is costly (I/O, validation, network).
• Desire to duplicate complex configuration quickly.

3. How It Works

• Prototype implements clone() (shallow or deep).
• Client calls clone() to obtain a copy and may tweak it.

4. Pros / Cons

5. Example (Python)

import copy

class Shape:
    def __init__(self, color): self.color = color
    def clone(self):
        return copy.deepcopy(self)

circle = Shape("red")
blue_circle = circle.clone()
blue_circle.color = "blue"

3 Conclusion

Creational Patterns are foundational:

• Open/Close Gatekeepers – conceal construction logic, yet stay open to new products.
• Separation of Concerns – distinguish what the client wants from how it is built.
• Maintainability & Testability – enable dependency inversion, mocking, and clean architecture.
• Scalability – frameworks, plug-ins, and micro-services routinely combine multiple creational patterns to stay tractable over time.
